HAVELLS, 4 Pole wSN, 320A, Loadline DIGITAL MCCB
Features of Digital Loadline MCCB
- Conforms to IS/IEC:60947-2
- Range: 250A to 630A
- Different Current Ratings provide selection option depending on varied load conditions.
- Ics = 75% of Icu
- Breaking Capacity Icu at 415V = 50kA
- Offered in different pole configurations based on system requirement
- Built in Ground Fault Protection in Four Pole Version
- Microprocessor based release with Adjustable Settings
- Electronic MCCB offers close, accurate & reliable protection against overload and short circuit fault
- True RMS Sensing
- Self Power Released - No external power required for basic functioning of the release
- Field Testing Provision - Built in operation to check function which helps in externally testing the release without energising the breaker
- Release setting using DIP Switches - Allows accurate setting, ensuring reliable system protection/ co-ordination
IHLLNFE40320
Data sheet
- RATED VOTAGE
- 415V AC
- TYPE OF NEUTRAL
- 4PwSN (Four Pole with Switched Neutral)
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- MICROPROCESSOR BASED
- MCCB FRAME
- LEN
- MCCB CURRENT RATING
- 320A
- MCCB/MPCB POLES
- 4 POLE
- MCCB/MCB BREAKING CAPACITY
- 50kA
