C&S, 4 Pole, 100A, ACE 2 MCCB

FMU (Thermal Magnetic) Release, Adjustable Overload 80-100%, Fixed short circuit 10In.

Features of ACE 2 MCCB

  • Conforms to IS/IEC 60947-2
  • Ics = 100% Icu
  • Range 16A to 1250A
  • Breaking Capacity: 36kA, 50kA & 70kA
  • FMU (Thermal Magnetic) Release
  • Adjustable Overload 80-100%
  • Fixed Short Circuit 10In
  • Neutral Protection 50% to 100%
  • Positive Isolation
  • Trip free mechanism
  • Double contact structure
  • No Line-load Bias
  • Wide range of internal & external accessories
  • Standard packing includes spreader terminals, insulating phase barrier & hardware.
CSCN125TM1004P

Data sheet

MCCB CONTROL VOLTAGE
415V AC
COUNTRY OF ORIGIN
INDIA
MCCB PROTECTION TYPE
THERMAL MAGNETIC BASED
MCCB FRAME
FRAME 1
MCCB CURRENT RATING
100A
MCCB/MPCB POLES
4 POLE
MCCB/MCB BREAKING CAPACITY
36kA
