L&T, 4 Pole, 63-80A, DU 100D MCCB
80A, DU 100D, THERMAL MAGNETIC RELEASE, DU MCCB
DU MCCBS
Features
- Confirms to IEC60947-2,EN60947-2,IS/IEC60947-2
- Adjustable Overload Setting ; 0.8- 1.0x in
- Internal Accessories:
- Auxiliary Contact
- Trip Alarm Contact
- Auxiliary+Trip Alarm Contact
- Shunt Release
- Under Voltage Release
- External Accessories:
- Direct & Extended Rotary Handle
- Spreader Terminals
- Key lock for Interlocking
- SS Enclosure
CM90518OOJO
Data sheet
- MCCB MODEL
- DU 100D
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- THERMAL MAGNETIC BASED
- MCCB CURRENT RATING
- 80A
- MCCB/MPCB POLES
- 4 POLE
- MCCB THERMAL/ MAGNETIC RELEASE RANGE
- 63-80A
- MCCB/MCB BREAKING CAPACITY
- 18kA
Specific References
New
