SIEMENS, 3 Pole, 1250A, ELECTRICAL DRAWOUT, SENTRON 3WT ACB
Withdrawable design with Guide Frame
SENTRON 3WT ACB
- Conforms to IEC 60947-2
- Rated current - 630A to 4000
- Uimp = 12kV
- Integrated communication & metering option
- Easy parameterization and diagnostics with Powerconfig
- Mechanical contact erosion indicator
- Fully rated upto 50°C
- Integrated LCD display and Online test facility
- Variants available for 690V AC applications
- Standard breaking capacity at 500V AC Ics = 100% Icu
- Microprocessor based trip unit: LSING + Display
- Standard Accessories included for draw out type ACB (EDO/MDO) = Safety shutter, sealing cap over Off button, door sealing frame, trip unit transparent cover, trip signaling contact, ready to close signaling contact, auxiliary contacts 2NO+ 2NC
3WT8121-6UA34-5AB2
Data sheet
- ACB TRIP UNIT
- ETU37WT LSING with Display
- ACB FRAME SIZE
- FRAME-I
- COUNTRY OF ORIGIN
- INDIA
- ACB POLES
- 3 POLE
- ACB PROTECTION TYPE
- MICROPROCESSOR BASED
- ACB RATING
- 1250A
- ACB TYPE & VERSION
- EDO
