C&S, 4 Pole, 2500A, MANUAL DRAWOUT, AHA ACB

LT Air Circuit Breaker fitted with Thermal Magnetic Release

Features of AH / AHA ACB

  • Rating 630-6300A
  • Circuit Breaker fitted with Thermal Magnetic Release
  • Dual spring balanced mechanism Rugged steel construction
  • High electrical & mechanical life Modular construction with most compact dimensions
  • Fastest opening & closing time Maintenance friendly features: slow closing, pole replacement, easy accessories fitment

AH / AHA Manual Draw-out ACB

  • Wide range of accessories
  • Auxiliary Switch 5NO+5NC
  • Main CTs
  • Safety Shutter
  • 24 Way Auxiliary Isolating contacts
  • Termination Type - Horizontal upto 2500A
  • Termination Type - Vertical for 3200-6300A
AHA25N4PMDOTM(S)

Data sheet

COUNTRY OF ORIGIN
INDIA
ACB BREAKING CAPACITY
50kA
ACB IN BUILT AUX.CONTACTS
5NO+5NC
ACB POLES
4 POLE
ACB PROTECTION TYPE
THERMAL MAGNETIC BASED
ACB RATING
2500A
ACB TYPE & VERSION
MDO

Specific References

New
