HAVELLS, 4 Pole wSN, 125A, Loadline DIGITAL MCCB
Features of Digital Loadline MCCB
- Conforms to IS/IEC:60947-2
- Range: 25A to 250A
- Different Current Ratings provide selection option depending on varied load conditions.
- Ics = 100% of Icu
- Breaking Capacity Icu at 415V = 35kA
- Offered in different pole configurations based on system requirement
- Built in Ground Fault Protection in Four Pole
- Microprocessor based release with Adjustable Settings
- Electronic MCCB offers close, accurate & reliable protection against overload and short circuit fault
- True RMS Sensing
- Self Power Released - No external power required for basic functioning of the release
- Field Testing Provision - Built in operation-check function which helps in externally testing the release without energising the breaker
- Release setting using DIP Switches - Allows accurate setting, ensuring reliable system protection/ co-ordination
IHLFEN40125
Data sheet
- RATED VOTAGE
- TYPE OF NEUTRAL
- COUNTRY OF ORIGIN
- MCCB PROTECTION TYPE
- MCCB FRAME
- MCCB CURRENT RATING
- MCCB/MPCB POLES
- MCCB/MCB BREAKING CAPACITY
