HAVELLS, 4 Pole wSN, 63A, Loadline MCCB
  • HAVELLS, 4 Pole wSN, 63A, Loadline MCCB

HAVELLS, 4 Pole wSN, 63A, Loadline MCCB

Features of Loadline MCCB

  • Conforms to IS/IEC:60947-2
  • Range: 25A to 160A
  • Different Current Ratings provide selection option depending on varied load conditions
  • Ics = 100% of Icu
  • Breaking Capacity Icu at 415V = 10kA
  • Offered in different pole configurations based on system requirement
  • Fixed Thermal & Fixed Magnetic Setting
  • Overload Setting is Fixed and Short Circuit Setting is minimum 10 times of Rated Current
  • Compact Size & Double Insulation
  • In 4Pwsn Version, Neutral make first & break last for addressing Residual Current in the Circuit
  • Provision of push to tip button
  • Positive dolly position indication to check the ON/OFF status of the breaker
  • Wide range of accessories available
IHLGSF0063

Data sheet

RATED VOTAGE
COUNTRY OF ORIGIN
MCCB PROTECTION TYPE
MCCB FRAME
MCCB CURRENT RATING
MCCB/MPCB POLES
MCCB/MCB BREAKING CAPACITY
