HAVELLS, 3 Pole, 80A, Loadline MCCB
Features of Loadline MCCB
- Conforms to IS/IEC:60947-2
- Range: 15A to 100A
- Different Current Ratings provide selection option depending on varied load conditions
- Ics = 50% of Icu
- Breaking Capacity Icu at 415V = 10kA
- Offered in different pole configurations based on system requirement
- Fixed Thermal & Fixed Magnetic Setting
- Overload Setting is Fixed and Short Circuit Setting is minimum 10 times of Rated Current.
IHLM1AAT0080
Data sheet
- RATED VOTAGE
- COUNTRY OF ORIGIN
- MCCB PROTECTION TYPE
- MCCB FRAME
- MCCB CURRENT RATING
- MCCB/MPCB POLES
- MCCB/MCB BREAKING CAPACITY
