SIEMENS, 22kW, SIRIUS 3RW40 DIGITAL SOFT STARTER
Features of SIRIUS 3RW40 Digital soft starters
- Range From 5.5 to 250 kW
- Operating voltage: 200-480V AC & 200-460V AC
- Control voltage: 24V AC/DC, 110-230V AC/DC, 115V AC, 230V AC
- Soft start, soft stop, adjustable current limit
- Integrated bypass contact system
- Integrated microprocessor based overload relay with adjustable trip class 10/15/20
- Intrinsic device protection to protect against thermal overloading of thyristors
- Integrated state and fault monitoring
- Innovative 2-phase “Polarity Balancing” operation.
3RW4036-1BB14
Data sheet
- TYPE OF STARTER
- DIGITAL SOFT STARTER
- RATED OPERATIONAL CURRENT
- 45/42/39A
- RATED OPERATIONAL VOLTAGE
- 200-480V
- CONTROL VOLTAGE
- 110-230V AC/DC
- OPERATING CURRENT RANGE
- 45/42/39A
- MOTOR STARTER MODEL
- SIRIUS 3RW40
- COUNTRY OF ORIGIN
- INDIA
- MOTOR KW
- 22
- MOTOR APPLICATION
- AGRICULTURE
