L&T, 5-40A, 1 Phase, DIN ENERGY METER
Features of 4000 Series DIN Type Energy Meter
- For energy monitoring of loads in distribution boards.
- These are primarily used for sub metering purposes.
- Parameters: 1 Phase -Voltage, Current, kW, kWh & 3 Phase -Voltage, Current, kW, kWh + PF, kVA, kVAr, MD
- DIN mounting whole current operated meter
- Accuracy Class 1 as per IEC 62053-21
- LCD display for clear display of parameter values
- Whole current operated. 5-40A for Single Phase and 10-60A for Three Phase
- Displays Push-to-Push consumption, Daily, Weekly, Monthly consumption
- Push button for parameter scrolling
- Terminal covers to avoid direct contact of the supply terminals along with sealing provision
- Energy recording at low currents
- Pulse output LED available
- Reverse current indication for three phase
- Compact size and easy mounting
- Additional RS485 module for communication over RS485 modbus RTU protocol
WD4000101OOO
Data sheet
- NO OF PHASES & WIRE
- 1PHASE
- COUNTRY OF ORIGIN
- INDIA
- CLASS OF ACCURACY
- 1
- CURRENT RATING
- 5-40A
- MOUNTING METHOD
- DIN RAIL MOUNTING
