L&T, 4 Pole, 16-63A, DZ1-160D MCCB
DZ1F0063DXH1A
Data sheet
- MCCB MODEL
- DZ1-160D
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- MICROPROCESSOR BASED
- MCCB CURRENT RATING
- 63A
- MCCB TRIP UNIT
- MTX 2.0
- MCCB/MPCB POLES
- 4 POLE
- MCCB THERMAL/ MAGNETIC RELEASE RANGE
- 16-63A
- MCCB/MCB BREAKING CAPACITY
- 36kA
