HAVELLS, 4 Pole wSN, 125A, Loadline DIGITAL MCCB Features of Digital Loadline MCCB
Conforms to IS/IEC:60947-2 Range: 25A to 250A Different Current Ratings provide selection option depending on varied load conditions. Ics = 75% of Icu Breaking Capacity Icu at 415V = 50kA Offered in different pole configurations based on system requirement Built in Ground Fault Protection in Four Pole Version Microprocessor based release with Adjustable Settings Electronic MCCB offers close, accurate & reliable protection against overload and short circuit fault True RMS Sensing Self Power Released - No external power required for basic functioning of the release Field Testing Provision - Built in operation to check function which helps in externally testing the release without energising the breaker Release setting using DIP Switches - Allows accurate setting, ensuring reliable system protection/ co-ordination Reference IHLFEH40125
Data sheet RATED VOTAGE 415V AC TYPE OF NEUTRAL 4PwSN (Four Pole with Switched Neutral) COUNTRY OF ORIGIN INDIA MCCB PROTECTION TYPE MICROPROCESSOR BASED MCCB FRAME FEH MCCB CURRENT RATING 125A MCCB/MPCB POLES 4 POLE MCCB/MCB BREAKING CAPACITY 50kA Condition New
