HAVELLS, 4 Pole wSN, 500A, Loadline MCCB
  • HAVELLS, 4 Pole wSN, 500A, Loadline MCCB

HAVELLS, 4 Pole wSN, 500A, Loadline MCCB

Features of Loadline MCCB

  • Conforms to IS/IEC:60947-2
  • Range: 200A to 630A
  • Different Current Ratings provide selection option depending on varied load conditions
  • Ics = 75% of Icu
  • Breaking Capacity Icu at 415V = 50kA
  • Offered in different pole configurations based on system requirement
  • In 4Pwsn Version, Neutral make first & break last for addressing Residual Current in the Circuit
  • Adjustable Thermal & Adjustable Magnetic Setting
  • Overload Setting is Adjustable Thermal 80-100% & Adjustable Magnetic 5-10 times of Rated Current
  • Compact Size & Double Insulation
  • Provision of push to tip button
  • Positive dolly position indication to check the ON/OFF status of the breaker
  • Wide range of accessories available
IHLLNFC40500

Data sheet

RATED VOTAGE
415V AC
COUNTRY OF ORIGIN
INDIA
MCCB PROTECTION TYPE
THERMAL MAGNETIC BASED
MCCB FRAME
LN
MCCB CURRENT RATING
500A
MCCB/MPCB POLES
4 POLE
MCCB/MCB BREAKING CAPACITY
50kA

Specific References

New
