![HAVELLS, 3 Pole, 320A, Loadline MCCB HAVELLS, 3 Pole, 320A, Loadline MCCB](https://techbaniya.in/38561-large_default/havells-3-pole-320a-loadline-mccb.jpg)
HAVELLS, 3 Pole, 320A, Loadline MCCB
Features of Loadline MCCB
- Conforms to IS/IEC:60947-2
- Range: 200A to 630A
- Different Current Ratings provide selection option depending on varied load conditions
- Ics = 100% of Icu
- Breaking Capacity Icu at 415V = 36kA
- Offered in different pole configurations based on system requirement
- In 4Pwsn Version, Neutral make first & break last for addressing Residual Current in the Circuit
- Adjustable Thermal & Adjustable Magnetic Setting
- Overload Setting is Adjustable Thermal 80-100% & Adjustable Magnetic 5-10 times of Rated Current
- Compact Size & Double Insulation
- Provision of push to tip button
- Positive dolly position indication to check the ON/OFF status of the breaker
- Wide range of accessories available
IHLLSEC30320
Data sheet
- RATED VOTAGE
- 415V AC
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- THERMAL MAGNETIC BASED
- MCCB FRAME
- LS
- MCCB CURRENT RATING
- 320A
- MCCB/MPCB POLES
- 3 POLE
- MCCB/MCB BREAKING CAPACITY
- 36kA
