HAVELLS, 1 Pole, 160A, Loadline MCCB

Features of Loadline MCCB

  • Conforms to IS/IEC:60947-2
  • Range: 40A to 160A
  • Different Current Ratings provide selection option depending on varied load conditions
  • Ics = 100% of Icu
  • Breaking Capacity Icu at 415V = 27kA & 36kA
  • For Single Pole Breaking Capacity (Icu) at 240V
  • Offered in different pole configurations based on system requirement
  • In 4Pwsn Version, Neutral make first & break last for addressing Residual Current in the Circuit
  • Adjustable Thermal & Fixed Magnetic Setting
  • Overload Setting is Adjustable Thermal 80-100% of Rated Current
  • Compact Size & Double Insulation
  • Provision of push to tip button
  • Positive dolly position indication to check the ON/OFF status of the breaker
  • Wide range of accessories available
IHA13DB10160

Data sheet

RATED VOTAGE
415V AC
COUNTRY OF ORIGIN
INDIA
MCCB PROTECTION TYPE
THERMAL MAGNETIC BASED
MCCB FRAME
HID1
MCCB CURRENT RATING
160A
MCCB/MPCB POLES
1 POLE
MCCB/MCB BREAKING CAPACITY
27kA
