L&T, 3 Pole, 40A, DZ1-160D MCCB
40A, DZ1-160D, THERMAL MAGNETIC RELEASE, D SINE MCCB FOR ISOLATION
Conforms to IS/IEC 60947-2 & IEC 60947-2, 3 Pole, Suitable for isolation, Ics=100% of Icu, Adjustable overload setting: 0.67 - 1.0 x In, Adjustable short circuit setting: 6 - 12 x In, Wide range of internal and external accessories, Transparent release cover.
DZ1T0040DXC1A
Data sheet
- MCCB APPLICATION
- ISOLATION
- MCCB MODEL
- DZ1-160D
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- THERMAL MAGNETIC BASED
- MCCB CURRENT RATING
- 40A
- MCCB/MPCB POLES
- 3 POLE
- MCCB/MCB BREAKING CAPACITY
- 36kA
