L&T, 4 Pole, 320-800A, DN4-1250S MCCB
800A, DN4-1250S, MICROPROCESSOR RELEASE, D SINE MCCB
Conforms to IS/IEC 60947-2 & IEC 60947-2, 4 Pole, Adjustable Over Load from 0.4 - 1.0 x In, Inbuilt ground fault protection from 10% - 50% of In, Advanced Current, Voltage, Frequency & Power based protections, Variable trip class at 1.5 Ir,6 Ir & 7.2 Ir, Panel mounted display available for advanced protections & metering, For 3 phase 4 wire system, External neutral CTs available for 3P MCCBs.
CM96115OOOOBG
Data sheet
- MCCB MODEL
- DN4-1250S
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- MICROPROCESSOR BASED
- MCCB CURRENT RATING
- 800A
- MCCB TRIP UNIT
- MTX 3.0
- MCCB/MPCB POLES
- 4 POLE
- MCCB THERMAL/ MAGNETIC RELEASE RANGE
- 320-800A
- MCCB/MCB BREAKING CAPACITY
- 70kA
