L&T, 3 Pole, 25-32A, DU 100H MCCB
32A, DU 100H, THERMAL MAGNETIC RELEASE, DU MCCB
- Conforms to IS/IEC 60947-2 & IEC 60947-2
- Compact size
- Common SS Enclosure
- Wide Range of snap fit Internal and External Accessories
- Adjustable Overload Setting: 0.8 - 1.0 x In
CM97894OOE2
Data sheet
- MCCB MODEL
- DU 100H
- COUNTRY OF ORIGIN
- INDIA
- MCCB PROTECTION TYPE
- THERMAL MAGNETIC BASED
- MCCB CURRENT RATING
- 32A
- MCCB/MPCB POLES
- 3 POLE
- MCCB THERMAL/ MAGNETIC RELEASE RANGE
- 25-32A
- MCCB/MCB BREAKING CAPACITY
- 30kA
Specific References
