L&T, 3 Pole, 63-160A, DN2-250N MCCB Conforms to IS/IEC 60947-2 & IEC 60947-2 Range: 40A to 1250A, 3P & 4P Choice of 36kA/ 50kA/ 70kA breaking capacitiesIcs = 100% Icu Adjustable Over Load setting: 0.4 - 1.0 x In Adjustable Short Circuit setting: 1.5 - 8 x Ir Inbuilt Instantaneous Protection Provision of Thermal Memory : ON/OFF Variable trip class at 7.2 lr & 6 lr Front LED indication of Over Load (Ready, Over load pre-alarm & Overload) Manual, Rotary or Motorised versions available @ Wide Range of snap fit Internal and External Accessories Reference CM92075OOOOX1
Data sheet MCCB MODEL DN2-250N COUNTRY OF ORIGIN INDIA MCCB PROTECTION TYPE MICROPROCESSOR BASED MCCB CURRENT RATING 160A MCCB TRIP UNIT MTX 1.0 MCCB/MPCB POLES 3 POLE MCCB THERMAL/ MAGNETIC RELEASE RANGE 63-160A MCCB/MCB BREAKING CAPACITY 50kA Condition New
