SCHNEIDER, 4 Pole, 1000A, ELECTRICAL FIXED, EasyPact MVS ACB
Advantages of EasyPact MVS ACB
- Thermal memory ensures safe tripping in case of consecutive faults
- In-built ZSI feature facilitates intelligent discrimination and enhances installation life
- Mechanical ready to close features checks all safety parameters before closing for enhanced safety
- Trip unit with built in current & voltage metering for easy access to important electrical parameter
- Best in class break time of 25ms creates lower stress on installation
- Pollution degree 4 allows the breaker to operate in harsh environments
- LED bargraph ensures easy access to % phase wise loading information
- Ap protection feature standard in all trip unit
- Single frame for 800A to 4000A
- Suitability for applications up to 690V
- Flexible terminal orientation enables horizontal or vertical alignment chnages in the field
EasyPact MVS Fixed ACB
- Conforms to IS/ IEC 60947-2 & 3
- Microprocessor based ET trip systems with thermal memory
- No derating up to 50˚C
- Zone Selective Interlocking
- Fully rated neutral with inbuilt protection
- Pre trip alarm & individual fault indicating LEDs
- Icu=Ics=Icw (1Sec)=50kA at 440V AC
Note: All Fix type circuit breakers will be supplied with: (i) Horizontal/Verical terminations. (ii) 1 No. Electrical fault indication Contact (SDE). (iii) No. Auxiliary contact block (OF) with 4 C/O contacts. (iv) Door sealing frame- Escutcheon (CDP). All Electrical operated breakers are supplied with motor mechnism (MCH), closing coil (XF) & shunt release (XF)
